£312.00 £342.64
The Eagle 5 with SplitShot™ HD from Lowrance is a user-friendly and advanced fish finder particularly suited for anglers looking for an easy-to-use, high-performance fish finder with advanced features and excellent visibility.
This 5-inch model benefits from the following features:
- FishReveal Technology: Combines CHIRP sonar and DownScan Imaging™ for better fish identification and target separation.
- Wide-Angle High CHIRP Sonar: Provides high-resolution views of individual fish targets.
- DownScan Imaging™: Offers photo-like images of underwater structures directly beneath the boat.
- Autotuning Sonar: Automatically adjusts sonar settings for optimal performance, saving time and effort.
- Screen: 5-inch IPS Screen: Higher resolution and better visibility from all angles, even in direct sunlight with polarized sunglasses (compared to older models).
- Preloaded Base map and Charting: This model comes with a worldwide base map chart and offers the option to upgrade to CMAP® Discover™ or other charting providers for detailed navigation.
- Genesis Live: This features allows the user to create custom 1/2-foot contour maps of local lakes or uncharted waters in real-time.
- New Connector System: Improved twist-locking connector for easy setup and removal.
- One-Year Warranty: Provides peace of mind with a one-year warranty guarantee.
The combination of CHIRP sonar, DownScan Imaging™, and FishReveal technology helps anglers identify and target fish effectively.
The improved IPS screen ensures clear and sharp images in various lighting conditions, improving the overall user experience (compared to previous models).
Autotuning sonar and the latest connector system make setup and adjustments quick and hassle-free.
The Genesis Live feature allows for precise mapping of local fishing spots, offering a significant advantage for serious anglers.
The preloaded base map with upgrade options ensures comprehensive coverage and detailed navigation aids.
Enhanced SplitShot™ HD Transducer with Autotuning sonar
Worldwide base map IPS screen, viewable from all angles, even in polarised glasses
Reliable twist-lock connector system for easy installation in any boat or kayak
SD card slot for software updates, Genesis Live recording and charting add-ons
See fish hiding in cover with FishReveal™ mode
Increase contrast and viewability with all-new Imaging colour palettes
Specification
Resolution | 800 x 480 |
Selection Guide | SplitShot HD Transducer |
Brand | Lowrance |
Screen Size | 5" |
Series | Eagle |
Model | Eagle 5 |
Voltage Description | 12V DC (10.8-17VDC) |
Fuse | Recommended Fuse Rating: 3A |
Height Description | 113.2 mm (4.46") |
Width | 182.1 mm (7.17") |
Depth | 110.6 (4.35") |
Weight | 0.46 kg (1.01 lb) |
Consumption | Max: 280 mA @ 12 V DC with backlight on full / Min: 190 mA @ 12 V DC with backlight off / Typical: 280 mA @ 12 V DC with backlight on full |
Operating Temperature | 5°F to 131°F (-15°C to 55°C ) |
Angle | Viewing: 80° top/bottom, 80° left/right |
Warranty | 1 Year + 4 additional years of upgrade options (totaling 5 years) |
Mounting Description | Gimbal bracket or dash mount |
